🔹 0 Mileage (Brand New)
🔹 18 Ton Payload
🔹 12m³ Bucket Capacity
Features
Turbo charged intercooled Engine With Mechanical Pump
180 hp ouptut for faster trips
6 Speed Eaton Gearbox with higher First Gear Ratio
Optimum Tare Weight for Higher Payload
Hydraulic Clutch Actuation for Minimum Pedal Effort
Full Air Dual Line Brakes
Unique Load body with Side unloading window Higher Load
Specifications
Engine: HA6ETI3U – 6 Cylinder Turbocharged Intercooled
Diesel with Inline Pump

Bore x Stroke: 104 x 113 mm

Displacement: 5759 cc

Maximum Output: 180 HP (135 kW) at 2400 RPM

Maximum Torque: 660 Nm at 1500 – 1700

Emission: Euro III

Air filter: Fleetguard with primary & safety element

Fuel filter: Fleetguard Fuel filter cum water separator

Cooling type: Pump circulated, thermostat controlled pressurised cooling with De-aeration tank

Clutch: Air boosted Hydraulically actuated single plate dry type 15″ RDC four finger clutch (Ceramic)

Gear Box: EATON 6 Speed Synchromesh gearbox

Propeller Shaft: 1710 Series
No. of shafts: 2 No

Rear Axle: Fully floating single speed hypoid gear Twin Rear Axle – Both Driven, Meritor Axle SQR 109

Axle capacity: 19000 kg

Axle Ratio: 6.17:1

Front Axle: Forged ‘I’ section reverse elliot

Axle capacity: 6000kg

Frame: All Steel Ladder Type Bolted

Suspension: Non-Reactive Semi-Elliptic laminated multileaf with center bolt arrangement

Steering: RANE Integral power assisted steering

Drive: RHD

Wheels & Tyres

Rim size: 7.5HD x 20″ – 160mm offset

Tyre size: 1000 x 20 – 16PR

Brakes: Full air – Dual line, S Cam

Parking brake: Spring actuated brakes on rear only
